Showing 1–12 of 18 results
![]()
Buy productMORE INFOPMAC201HW 12 channel Power Meter
- Suit for voltage under 330V (L-N)/570V(L-L) (direct)
- Used for 4×3 phase or 12×1 phase circuit AC measuring
- Support 100mA rated current input，CT primary up to 5000A
- Auto-distinguish mix connection of three phase and single phase
- Different circuit can be set to different current
- Ture-RMS measuring parameter for U; I; P; Q; S; PF; F; kWh(Imp. & Exp.); kvarh (Imp. & Exp.); Demand & Max./Min. value (P),TOU (multi-tariff) function
- 4 tariffs; 8 time period in 24 hours
- Data logging per 15 min; Max. Memory 40 day’s data
- SOE (event log) Record
- Build-in MODBUS-RTU via RS485 port
- LED light indicates Pulse Output
- Run status and Communication status
- Standard 35mm DIN rail Mount
![]()
Buy productMORE INFOPMAC202 AC Branch Circuit Power Meter
- 1 main circuit + 42 branch circuit
- DI module to monitor each branch circuit status
- Touch screen HMI with build-in system for setting and data display
- High accuracy IEC62053-22 class 1.0
- Build-in MODBUS-RTU via RS485 port
- Settable alarm function for voltage; current; current unbalance
- optional alarm for leakage current & temperature
- Measuring current up to 200A
- Programmable phase sequence for branch circuit; settable to single phase or three phase
- Historical kWh record for last 12 months and last 10 years
![]()
Buy productMORE INFOPMAC203 DC Branch Circuit Power Meter
- Measuring: 1 main circuit + 42 branch circuits, Hall sensor zero point calibration
- DI: 4 status inputs (dry contact) for Main breaker and Lightning protection switch,
- DO: 2 relay outputs for alarm, 1 pulse output
- Settable Pre-Alarm function:
- Main circuit: Alarm for voltage, current, load, breaker status. Option alarm for Insulation resistance and temperature.
- Branch circuit: Alarm for current (lo-lo-limit, lo-limit, hi-limit, hi-hi-limit), breaker status. Option Insulation resistance .
- Communication: RS485, support Modbus-RTU protocol
- Optional Hall Sensor input for Main circuit: 100A, 200A, 400A, 600A, 800A, 1600A
- Optional Hall Sensor input for Branch circuit: 50A, 100A, 200A
- Hall sensor zero point calibration
- Optional mean and branch circuit status monitor
- Temperature and isolation monitor
- Historical kWh record:
- kWh yearly consumption of last 10 years,
- kWh monthly consumption of last 12 months
![]()
Buy productMORE INFOPMAC211 Multi-Circuit Energy Meter
- Suit for 3 phase 4 wire connection mode
- Used for 4×3 phase AC measuring
- LCD display U, I, P, Q, S, PF, F, kWh, kvarh
- Over & Under limit alarm, up to 500 alarm records
- Max. measure current up to 600A
- 33.3mA & 100mA rated current input (optional)
- LED light indicates alarm & communication status
- Standard 35mm DIN Rail Mount
![]()
Buy productMORE INFOPMAC615 Single Phase Digital Panel Meter
- Accept standard CT input
- Direct connect to max. 400V voltage system
- Active energy accuracy is in accordance with IEC62053-21, class 1
- Accuracy of voltage and current measurement is 0.2%
- Friendly LED panel for reading
- Revisable relay alarm output
- Optional two status input
- Pluggable terminals, easy for wiring and maintain
- RS485 communication, support standard MODBUS-RTU protocol
- Operating temperature: -20℃ – +60℃
Storage temperature: -30℃ – +70℃
Humidity: 5% – 90%RH, non-condensing
![]()
Buy productMORE INFOPMAC625 Three-phase Digital Panel Meter
- Combination of remote signalling, remote control, remote metering and remote sensing
- Compact design with full measurement
- Communication RS485 Modbus
- Power supply: 85~265VAC, or 80~300VDC
- Simulate OLED display, high definition and high brightness
- Panel size: 96 x 96mm
- Programmable CT (1 ~ 9,999)
- Optional digital input, relay alarm output, 4-20mA output
- Installation dimension: 89.5 x.89.5mm, depth: 65mm
![]()
Buy productMORE INFOPMAC770 / PMAC770 – DR Multifunction Power Meter
- Suit for LV & HV voltage system
- High accuracy IEC62053-22 class 0.5s
- Build-in MODBUS-RTU via RS485 port
- Pluggable modules for BACnet MS/TP; Ethernet, DI; DO; AI; AO
- 64M bit data logging with build-in web server
- C02 carbon dioxide emission calculation
- True-RMS
- Time-of-use and power quality monitoring
- CE / KEMA / UL / CATIII certificate
![]()
Buy productMORE INFOSolid Core Current Transformer
The CTSB Series of split core style current transformers are designed for fast and easy installation. The split core design permits non-contact current measurements through magnetic field induction without disconnecting cables or busbar circuits for CT installation. This method permits a safer, easier and portable current measurement.
![]()
Buy productMORE INFOSplit Core Current Transformer
The CTSB Series of split core style current transformers are designed for fast and easy installation. The split core design permits non-contact current measurements through magnetic field induction without disconnecting cables or busbar circuits for CT installation. This method permits a safer, easier and portable current measurement.
![]()
Buy productMORE INFOSPM20 CMS Circuit Monitoring System
SPM20 series is a multi-channel power meter which measure both AC and DC and mixed current up to 63A. It is smallest size in the industry consists of main unit and sensor, use RJ12 port for easy connection.
For AC Type it support up to 30 Channels (10* 3 three phase power meter or 10* 1 single phase power meter). For DC Type it support up to 12 Channel (12*1 single phase power meter).
Applications
- Hotel, Hospital, Dormitory
- Commercial Building, Office
- Residential Building
- Reconstruction Project
